Formula M
4152035050
• Max Working Pressure (bar) : 10
• Vessel size (lt) : 0
• Configuration : Full Feature
• Motor (kw) : 30
• Noise Level : 72
• Max Working Pressure (bar) : 10
• Vessel size (lt) : 0
• Configuration : Full Feature
• Motor (kw) : 30
• Noise Level : 72
The Formula/Genesis MI 30-45 range you obtain an efficient, reliable and complete solution which fits a wide range of compressed air requirements. Reduced energy consumption up to 30% with variable driven technology. No long-term loss thanks to the combination of screw rotors and gearbox technology. In-house designed element with high performance, Standard IP 55 class F IE3 motor, Optimal ventilation flow is assured with low energy consumption, with a quiet air compressor with sound levels ranging between 72-75 dB (A). Easy to service thanks to the large hinged doors and removable panels. Easy to install thanks to a high variety of configurations and scope of supply. Airlogic² S Swipe controller is truly state-of-the-art, maximizing user-friendliness, efficiency and reliability.
The Formula/Genesis MI 30-45 range you obtain an efficient, reliable and complete solution which fits a wide range of compressed air requirements. Reduced energy consumption up to 30% with variable driven technology. No long-term loss thanks to the combination of screw rotors and gearbox technology. In-house designed element with high performance, Standard IP 55 class F IE3 motor, Optimal ventilation flow is assured with low energy consumption, with a quiet air compressor with sound levels ranging between 72-75 dB (A). Easy to service thanks to the large hinged doors and removable panels. Easy to install thanks to a high variety of configurations and scope of supply. Airlogic² S Swipe controller is truly state-of-the-art, maximizing user-friendliness, efficiency and reliability.
| Specification | Value |
|---|---|
| Weight | 723 KGM |
| Specification | Value |
|---|---|
| Performance data | |
| Min Working Pressure (bar) | 5 Bar |
| Max Working Pressure (psi) | 145 PSI |
| Max Working Pressure (Bar) | 10 Bar |
| Pump speed | n.a. Rpm |
| Vessel size (lt) | 0 Liter |
| Vessel size (gal) | 0 Gal |
| Configuration | Full Feature |
| FAD Capacity Max (l/min) | 5304 l/min |
| Pump element | S90 |
| oise Level | 72 dB(A) |
| Motor (hp) | 40 Hp |
| Motor (kw) | 30 kW |
| Supply voltage | 440 V |
| Frequency | 60 Hz |
| Number of phases | 3 |
| Air connector | 1 1/4'' |
| Oil capacity | 22 Liter |
| Dimensionals product | |
| Length | 1810 mm |
| Height | 1555 mm |
| Width | 830 mm |
| Part number | Motor (hp) | Vessel size (lt) | Number of phases | Price and availability | ||
|---|---|---|---|---|---|---|
| Part number | Motor (hp) | Vessel size (lt) | Number of phases | Price and availability | ||
4152034936 Abac Formula MI 30kW Variable Speed Screw Compressor - 10bar | 40 Hp | 0 Liter | 3 | - | ||
4152034936 Abac Formula MI 30kW Variable Speed Screw Compressor - 10bar | 40 Hp | 0 Liter | 3 | - | ||
4152034937 Abac Formula MI 37kW Variable Speed Screw Compressor - 10bar | 50 Hp | 0 Liter | 3 | - | ||
4152034937 Abac Formula MI 37kW Variable Speed Screw Compressor - 10bar | 50 Hp | 0 Liter | 3 | - | ||
4152034938 Abac Formula MI 45kW Variable Speed Screw Compressor - 10bar | 60 Hp | 0 Liter | 3 | - | ||
4152034938 Abac Formula MI 45kW Variable Speed Screw Compressor - 10bar | 60 Hp | 0 Liter | 3 | - | ||
4152034939 Abac Formula MI 30kW Variable Speed Screw Compressor - 13bar | 40 Hp | 0 Liter | 3 | - | ||
4152034939 Abac Formula MI 30kW Variable Speed Screw Compressor - 13bar | 40 Hp | 0 Liter | 3 | - | ||
4152034940 Abac Formula MI 37kW Variable Speed Screw Compressor - 13bar | 50 Hp | 0 Liter | 3 | - | ||
4152034940 Abac Formula MI 37kW Variable Speed Screw Compressor - 13bar | 50 Hp | 0 Liter | 3 | - | ||
4152034941 Abac Formula MI 45kW Variable Speed Screw Compressor - 13bar | 60 Hp | 0 Liter | 3 | - | ||
4152034941 Abac Formula MI 45kW Variable Speed Screw Compressor - 13bar | 60 Hp | 0 Liter | 3 | - | ||
4152034966 Abac Formula MEI 30kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 40 Hp | 0 Liter | 3 | - | ||
4152034966 Abac Formula MEI 30kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 40 Hp | 0 Liter | 3 | - | ||
4152034967 Abac Formula MEI 37kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 50 Hp | 0 Liter | 3 | - | ||
4152034967 Abac Formula MEI 37kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 50 Hp | 0 Liter | 3 | - | ||
4152034968 Abac Formula MEI 45kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 60 Hp | 0 Liter | 3 | - | ||
4152034968 Abac Formula MEI 45kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 60 Hp | 0 Liter | 3 | - | ||
4152034969 Abac Formula MEI 30kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 40 Hp | 0 Liter | 3 | - | ||
4152034969 Abac Formula MEI 30kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 40 Hp | 0 Liter | 3 | - | ||
4152034970 Abac Formula MEI 37kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 50 Hp | 0 Liter | 3 | - | ||
4152034970 Abac Formula MEI 37kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 50 Hp | 0 Liter | 3 | - | ||
4152034971 Abac Formula MEI 45kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 60 Hp | 0 Liter | 3 | - | ||
4152034971 Abac Formula MEI 45kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 60 Hp | 0 Liter | 3 | - | ||
4152035008 Abac Formula MI 30kW Variable Speed Screw Compressor - 10bar | 40 Hp | 0 Liter | 3 | - | ||
4152035008 Abac Formula MI 30kW Variable Speed Screw Compressor - 10bar | 40 Hp | 0 Liter | 3 | - | ||
4152035009 Abac Formula MI 37kW Variable Speed Screw Compressor - 10bar | 50 Hp | 0 Liter | 3 | - | ||
4152035009 Abac Formula MI 37kW Variable Speed Screw Compressor - 10bar | 50 Hp | 0 Liter | 3 | - | ||
4152035010 Abac Formula MI 45kW Variable Speed Screw Compressor - 10bar | 60 Hp | 0 Liter | 3 | - | ||
4152035010 Abac Formula MI 45kW Variable Speed Screw Compressor - 10bar | 60 Hp | 0 Liter | 3 | - | ||
4152035011 Abac Formula MI 30kW Variable Speed Screw Compressor - 13bar | 40 Hp | 0 Liter | 3 | - | ||
4152035011 Abac Formula MI 30kW Variable Speed Screw Compressor - 13bar | 40 Hp | 0 Liter | 3 | - | ||
4152035012 Abac Formula MI 37kW Variable Speed Screw Compressor - 13bar | 50 Hp | 0 Liter | 3 | - | ||
4152035012 Abac Formula MI 37kW Variable Speed Screw Compressor - 13bar | 50 Hp | 0 Liter | 3 | - | ||
4152035013 Abac Formula MI 45kW Variable Speed Screw Compressor - 13bar | 60 Hp | 0 Liter | 3 | - | ||
4152035013 Abac Formula MI 45kW Variable Speed Screw Compressor - 13bar | 60 Hp | 0 Liter | 3 | - | ||
4152035050 Abac Formula MEI 30kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 40 Hp | 0 Liter | 3 | - | ||
4152035050 Abac Formula MEI 30kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 40 Hp | 0 Liter | 3 | - | ||
4152035051 Abac Formula MEI 37kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 50 Hp | 0 Liter | 3 | - | ||
4152035051 Abac Formula MEI 37kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 50 Hp | 0 Liter | 3 | - | ||
4152035052 Abac Formula MEI 45kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 60 Hp | 0 Liter | 3 | - | ||
4152035052 Abac Formula MEI 45kW Variable Speed Screw Compressor with Integrated Dryer - 10bar | 60 Hp | 0 Liter | 3 | - | ||
4152035053 Abac Formula MEI 30kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 40 Hp | 0 Liter | 3 | - | ||
4152035053 Abac Formula MEI 30kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 40 Hp | 0 Liter | 3 | - | ||
4152035054 Abac Formula MEI 37kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 50 Hp | 0 Liter | 3 | - | ||
4152035054 Abac Formula MEI 37kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 50 Hp | 0 Liter | 3 | - | ||
4152035055 Abac Formula MEI 45kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 60 Hp | 0 Liter | 3 | - | ||
4152035055 Abac Formula MEI 45kW Variable Speed Screw Compressor with Integrated Dryer - 13bar | 60 Hp | 0 Liter | 3 | - | ||
8153340079 Abac Formula MI 55kW Variable Speed Screw Compressor - 10bar | 75 Hp | 0 Liter | 3 | - | ||
8153340079 Abac Formula MI 55kW Variable Speed Screw Compressor - 10bar | 75 Hp | 0 Liter | 3 | - | ||
8153340080 Abac Formula MI 75kW Variable Speed Screw Compressor - 10bar | 100 Hp | 0 Liter | 3 | - | ||
8153340080 Abac Formula MI 75kW Variable Speed Screw Compressor - 10bar | 100 Hp | 0 Liter | 3 | - |
